High Speed Chain Link Fencing Machine

Junen Automatic Chain Link Fence Machine can make various specifications of chain link fences up to MAX. 6 meters wide. The machine is suitable for different types of wires according to customer's requirement, such as galvanized wire, PVC coated wire, and SUS wire. There are two options for our customers to choose from standard type automatic machine to fully servo high speed machine. Our new design of quick-change weaving mould (twin worm) for fully servo type enables better efficiency in changing mesh size.

*For special specification requirements, please send us your inquiry.

Mesh Specifications

Fully Servo Type And Standard Type

  • Max. Output:210 ~ 240 m²/Hr.
  • Materials:G.I. Wire/ Stainless Steel Wire / PVC Coated Wire
  • Working Width:2m / 3m / 4m / 5m / 6m
  • Wire Dia. Range:2.0 – 5.0mm (G.I. Wire)
  • Mesh Size: Normally 2"(50 mm), 3"(80 mm), 4" (105mm)
  • Max. Speed:1200 rpm
  • Compact Recoiler Available
    * Upon the wire quality and mesh size
    **Subject to change with different M/C.

Standard Type

  • Max. Output:120 m²/Hr.
  • Wire Dia. Range:2.0mm – 4.2mm (G.I. wire)
  • Mesh Size:25mm–100mm
  • Speed:360 rpm
Machine Video

Automatic Chain Link Fencing Machine (Working Width MAX. 6M )
